LPR-1,8
This Orange peel rectangular Core scrap, pig-iron, pellets, OA scrap, ferro alloys, industrial heavy wastes, small packages pf scrap, etc.
- Hydraulic unit equipped with a self-regulating variable-displacement piston pump for efficient and controlled operation.
- Specially profiled jaws with side closing plates, designed to apply maximum penetration force for efficient load handling.
- Fully protected hydraulic cylinders for enhanced durability and protection during demanding operations.
- Special penetration teeth manufactured from wear-resistant manganese steel for increased strength and extended service life.
- Structure validated through Finite Element Analysis (FEA) to ensure structural strength, stability, and reliability.
Max. material density
1.8 T/M3
Structure
Rectangular
References
| Reference | Capacity | Engine 40% ED | Intensity 400 V | Working pressure | Closing time | Opening time | Crane SWL | Weight | Dimensions mm | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| m3 | kW | A | bar | s | s | t | kg | A | B | C | D | E | F | |
| LPR8-1500-1,8 | 1,5 | 20,5 | 39 | 130 | 10 | 6 | 8 | 4100 | 2950 | 2750 | 1820 | 2730 | 2000 | 800 |
| LPR8-2000-1,8 | 2 | 25,5 | 48,5 | 170 | 10 | 6 | 8 | 4400 | 3020 | 2820 | 2040 | 2840 | 2000 | 800 |
| LPR8-2500-1,8 | 2,5 | 31,5 | 61 | 140 | 12 | 7 | 10 | 5500 | 3780 | 3320 | 2190 | 3560 | 2000 | 900 |
| LPR8-3000-1,8 | 3 | 31,5 | 61 | 170 | 12 | 7 | 12,5 | 6300 | 3840 | 3350 | 2290 | 3620 | 2000 | 900 |
| LPR8-3500-1,8 | 3,5 | 51 | 94 | 130 | 13 | 8 | 16 | 8100 | 4090 | 3770 | 2320 | 3630 | 2300 | 1200 |
| LPR8-4000-1,8 | 4 | 51 | 94 | 140 | 13 | 8 | 16 | 8500 | 4170 | 3850 | 2460 | 3750 | 2300 | 1200 |
| LPR8-5000-1,8 | 5 | 62,5 | 117 | 175 | 13 | 8 | 20 | 9200 | 4320 | 3990 | 2730 | 4000 | 2300 | 1200 |
